Brake Control Mechanisms >> Quick Release Valve >> Seddon Atkinson >> Quick Release Valve For Seddon Atkinson
  | ||
| Product Name | Quick Release Valve | |
| Product No. | ABRS802-SA001 | |
| Parameter | Max.Operating Pressure(bar) | 10 |
| Operating Temperature Range | -40℃ ~ +80℃ | |
| Nominal Diameter(mm) | - | |
| Port 1 | 1/2" PTF SAE short | |
| Port 2 | 3/8" NPTF (2x) | |
| Port 3 | M 22x1.5 | |
| Remark | - | |
| Wabco No. | OEM No. | Application |
| 973 500 026 0 | 953093S1 | Seddon Atkinson |
