| Product Name | Foot Brake Valve | |
| Product No. | ABRS805-NE014 | |
| Parameter | Max. Operating Pressure(Bar) | 10 |
| Operating Temperature Range | -40℃~+80℃ | |
| Port Thread | 4x M 16x1.5; 2x M 12x1.5; 2x M 12x1.5 | |
| Basic Valve | 461 315 083 0 | |
| Nominal Diameter | 10 | |
| Predominance(Bar) | 0 | |
| Exhaust | M 22x1.5 | |
| Pedal Angle | 25° | |
| Actuation | - | |
| Remark | Exhaust angled at 40° | |
| Wabco No. | OEM No. | Application |
| 461 324 009 0 | 1518808 | DAF |
| 222784 | Iveco | |
| 81521306097 | Man | |
| 81521309097 | ||
| 11017328 | Neoplan | |
| 110241100 | ||
