| Product Name | SoleNoid Valve | |
| Product No. | ABRS810-RE004 | |
| Parameter | Operating Pressure(Bar) | Max. 10 |
| Type | Vented | |
| OperatingTemperature Range | -40¡æ~+100¡æ | |
| Port Thread | M 12x1.5 | |
| Port 4 | M 27x1 | |
| Duty Cycle | Continuous | |
| Protection Type(IP Code) | IP 68 | |
| Grade of insulation | ||
| Nominal Diameter | 2.2 /3 | |
| Voltage(V) | 24 | |
| Rated Current(A) | 0.43 | |
| Remark | - | |
| Wabco No. | OEM No. | Application |
| 472 123 198 0 | 1518101 | DAF |
| 0039971436 | Daimler | |
| A0039971436 | ||
| 11047717 | Neoplan | |
| 240612600 | ||
| 5000815631 | Renault Trucks | |
