Product Name |
Single Raised Foundation (Casting Type) |
|
Product No. |
MHAE221-CS001 |
|
Material |
Heat treatable steel |
|
Min.Breaking Loads Tension |
500KN |
|
Shear |
420KN |
|
Min.Breaking Loads Compression |
2000KN |
|
Weight |
7.0kg |
|
Finish |
Weldable shop primer |
|
Certification |
All items are approved by major classification societies |
|
Remark |
1.Centre marking for easy installation |
|
2.We can produce the products according to your request. |
