Product Name |
Double Stacking Cone | ||
|
Type |
Transversal Type | ||
|
Material |
Ship building steel | ||
|
Min.Breaking Loads Shear |
500KN | ||
|
Min.Breaking Loads Compression |
800KN | ||
|
Finish |
Hot dip galvanized | ||
|
Certification |
All items are approved by major classification societies | ||
|
Product No. |
LC(mm) | L(mm) | Weight(kg) |
|
MHAE221-DI002-01 |
203 | 333 | 9.0 |
|
MHAE221-DI002-02 |
216 | 346 | 9.3 |
|
MHAE221-DI002-03 |
258 | 388 | 9.5 |
|
Remark Other material and finish according to your request. | |||
