GD Type Rubber Fender | |||||
|---|---|---|---|---|---|
| Product No. |
Spec. H*B*L |
L | Q | P | Bolt holes |
| MOME107-GD001 | DO280*540*1000 | 1000 | 150 | 700 | 2 |
| MOME107-GD002 | DO280*540*1500 | 1500 | 150 | 600 | 3 |
| MOME107-GD003 | DO280*540*2000 | 2000 | 145 | 570 | 4 |
| MOME107-GD004 | DO280*540*2500 | 2500 | 150 | 550 | 5 |
| MOME107-GD005 | DO280*540*3000 | 3000 | 150 | 540 | 6 |
| MOME107-GD006 | DO300*600*1000 | 1000 | 150 | 700 | 2 |
| MOME107-GD007 | DO300*600*1500 | 1500 | 150 | 600 | 3 |
| MOME107-GD008 | DO300*600*2000 | 2000 | 145 | 570 | 4 |
| MOME107-GD009 | DO300*600*2500 | 2500 | 150 | 550 | 5 |
| MOME107-GD010 | DO300*600*3000 | 3000 | 150 | 540 | 6 |
| MOME107-GD011 | DO300*540*1000 | 1000 | 150 | 700 | 2 |
| MOME107-GD012 | DO300*540*1500 | 1500 | 150 | 600 | 3 |
| MOME107-GD013 | DO300*540*2000 | 2000 | 145 | 570 | 4 |
| MOME107-GD014 | DO300*540*2500 | 2500 | 150 | 550 | 5 |
| MOME107-GD015 | DO300*540*3000 | 3000 | 150 | 540 | 6 |
|
Feature GD Type fender is the improved generation of D Type fender, it can be fixed with double line anchrs which greatly increase the imstallation stability, it also can be integreated into other fender system to reach the purpose of protecting the ships and docks. Metal Accessories:Bolt,Washer, Pre-bulit in nut. | |||||
