Lange Drag Head |
|||||
Product No. |
MDRE080-DH002 |
||||
* Efficient hydraulic design. |
|||||
* Adjustable visor (gravity). |
|||||
* Replaceable teeth system. |
|||||
* Replaceable wear blocks. |
|||||
* Wear resistant side skirts. |
|||||
* Grid to prevent blockage with boulders. |
|||||
* Rubber fenders to protect ship's hull and gantries. |
|||||
Product No. |
Diameter |
Length Overall |
Length of Visor |
Width overall |
Width of Visor |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
|
MDRE080-DH201 |
420 |
1300 |
1000 |
1600 |
1340 |
MDRE080-DH202 |
550 |
1525 |
1100 |
1800 |
1560 |
MDRE080-DH203 |
600 |
1560 |
1190 |
1850 |
1560 |
MDRE080-DH204 |
650 |
1900 |
1240 |
2650 |
2550 |
MDRE080-DH205 |
700 |
1935 |
1255 |
2700 |
2600 |
MDRE080-DH206 |
750 |
1950 |
1300 |
2810 |
2700 |
MDRE080-DH207 |
800 |
2000 |
1550 |
2940 |
2750 |
MDRE080-DH208 |
900 |
2350 |
1650 |
3200 |
2850 |
MDRE080-DH209 |
1000 |
2850 |
1760 |
3700 |
3250 |
MDRE080-DH210 |
1200 |
3300 |
1850 |
4240 |
3700 |
Other specification are available upon request. |
|||||
