Marine Air Compressors >> Reciprocating Compressor >> Water-Cooled Air Compressor >> High Pressure CompressorWater Cooled Marine Reciprocating Air Compressor

Product Name	High-Pressure Marine Reciprocating Air Compressor
Product Features
Cylinder Arrangement	Single Row Vertical Type
Stage	Three Stage Compression Piston-style
Cooled Type	Cooled Water
Discharge Capacity	0.27-0.43 m3/min
Discharge Pressure	6.0-19.6 Mpa
Compact construction , small size, light weight and high pressure
Technical Data
Product No.	Capacity	Pressure	Speed	Motor Power	Weight	Dimension
	m3/min	Mpa	r/min	kw	kg	mm
MCAS104-AC201	0.27	14.7	970	7.5	300	1100*500*950
MCAS104-AC202	0.27	14.7	1000	7.5	210	555*585*940
MCAS104-AC203	0.42	14.7	1460	11	330	1100*500*950
MCAS104-AC204	0.42	14.7	1500	11	270	620*650*1000
MCAS104-AC205	0.43	6.0	1460	11	330	1100*500*950
MCAS104-AC206	0.43	6.0	1500	11	270	620*650*1000
MCAS104-AC207	0.41	19.6	1460	11	350	1100*520*950
Advantage
Compact construction,small size,light weight and high pressure
Application
Main used for Defense area, Starting the main engine of ships and the work of water to breathe
