Marine Valves >> DIN Marine Valves >> Check Valves >> PN40 Cast Steel Lift Check Globe ValvePN 40 Cast Steel Lift Check Globe Valve
  | |||||
| Product Name | PN 40 Cast Steel Lift Check Globe Pattern Valve | ||||
| Product NO | Size | L | D | C | n-d |
| MFVEHC4-DIN 01 | 015 | 130 | 95 | 65 | 4-14 |
| MFVEHC4-DIN 02 | 020 | 150 | 105 | 75 | 4-14 |
| MFVEHC4-DIN 03 | 025 | 160 | 115 | 85 | 4-14 |
| MFVEHC4-DIN 04 | 032 | 180 | 140 | 100 | 4-18 |
| MFVEHC4-DIN 05 | 040 | 200 | 150 | 110 | 4-18 |
| MFVEHC4-DIN 06 | 050 | 230 | 165 | 125 | 4-18 |
| MFVEHC4-DIN 07 | 065 | 290 | 185 | 145 | 8-18 |
| MFVEHC4-DIN 08 | 080 | 310 | 200 | 160 | 8-18 |
| MFVEHC4-DIN 09 | 100 | 350 | 235 | 190 | 8-22 |
| MFVEHC4-DIN 10 | 125 | 400 | 270 | 220 | 8-25 |
| MFVEHC4-DIN 11 | 150 | 480 | 300 | 250 | 8-25 |
| MFVEHC4-DIN 12 | 200 | 600 | 375 | 320 | 12-30 |
Click here to contact me!
