| HSC Batteryless Telephone System | ||||
| Product No: MEIC204 | ||||
| The HSC system is independeng of the vessels power supply and fulfills the demands for emergency | ||||
| communication between vital positions on broad. | ||||
| The HSC system can be deliveRed as : | ||||
| Selective calling system consisting of several multi-way type telephones which can call each other | ||||
| Commanding batteryless telepone system consisting of one commanding telephone and several | ||||
| multi-way telephones .commanding telephone can communicate with any multi-way telephone while | ||||
| multi-way telephones canot call each other. | ||||
| Features: | ||||
| 1)The system may also be connected to an external 24VDC power supply to ensure continuous operation | ||||
| under normal conditions.The system automatically switches to batteryless and ermergency operation in | ||||
| case of mains power failure. | ||||
| 2)With one call key on the panel of the HSC telephones.Press this key to call other telephones | ||||
| without rotating the call generator under 24VDC power supply.When the power voltage is between | ||||
| 15V and 35V,the system can still work normally.Rotate the call generator for the converstaion in | ||||
| case of mains power failure. | ||||
| 3)Headset type batteryless telephones can be used under 110dB noisy environment | ||||
| 4)Signal device is used in the engine room and other noisy area.The telephones all with terminals | ||||
| to connect the signal device. | ||||
| No | Model | Name | Weight | IP Class |
| 1 | HSC-1G | Wall type single-way batteryless telephone | 1kg | IP 44 |
| 2 | HSC-1Q | Flush type single-way batteryless telephone | 0.8kg | IP 20 |
| 3 | HSC-1F | Weather proof single-way batteryless telephone | 6.9kg | IP 56 |
| 4 | HSC-1J | Headset single-way batteryless telephone | 1.2kg | IP 44 |
| 5 | HSC-4/12G | 4-12 Wall type multi-way batteryless telephone | 1kg | IP 44 |
| 6 | HSC-4/12Q | 4-12 Flush type multi-way batteryless telephone | 0.8kg | IP 20 |
| 7 | HSC-4/12J | 4-12 Headset multi-way batteryless telephone | 1.2kg | IP 44 |
| 8 | HSC-4/12F | Weather proof multi-way batteryless telephone | 6.9kg | IP 56 |
| 9 | FR-100 | Relay box | 0.8kg | IP 44 |
| 10 | FR-100Z/FR-100J | Flashing Light signalling unit DC24V/AC220V) | 0.8kg | IP 44 |
| 11 | HSC-1/12G-EX | Explosion proof batteryless telephone | 3.5kg | IP 44 |
| 12 | S802A | Zener safety barrier(for single-way type) | 0.5kg | IP 44 |
| 13 | S816 | Zener safety barrier(for multi-way type) | 3.5kg | IP 44 |
| 14 | XD-1 | Portable junction box | 4kg | IP 22 |
| 15 | HX-8/12 | 8-12 junction box | 2-8kg | IP 22 |
