Reduction Gearbox >> Heavy Duty >> Marine Reduction Gearbox
  |
||||||
| Marine Reduction Gearbox | ||||||
| Product No. | Inpt spd(RPM) | RATIO | Trans.Capacity/Rate (HP/RPM) |
Thrust(KN) | NetWeight (kg/lb) |
Reversal Step |
| MPPE213-HS05 MPPE213-HL05 |
400~800 400~1000 400~1200 400~1400 400~1600 400~1600 400~1600 400~1600 400~1600 |
1.9750 2.4690 3.052 3.48 4.051 4.484 4.996 5.506 5.989 |
3.26 2.54 2.11 1.82 1.59 1.41 1.25 1.13 1.03 |
175 | 3250/7165 2820/6217 |
Yes No |
| Features | ||||||
| * Both are coaxial, and have double-step reduction, the same sense of rotation in input and output shaft. * Available for us to design solutions for the entire propulsion system, like gearbox, shafting, coupling, propeller, etc * All products available approved by ABS,BV,CCS,DNV,GL,LR,NK,etc., Certificated of Quality System ISO9001:2000 * Click to contact me for more technical details | ||||||
