Marine Solid Waste Management System >> Marine Incinerator >> Single Function Incinerator >> Solid Waste TypeMarine Incinerator
 |
 |
| Product Name | Marine Incinerator |
| Product No. | MEPE401-SW002 |
| Waste Type | Solid Waste |
| Mounting Type | Vertically |
| Power Supply | 440V/60HZ 380V/50HZ |
| Calorie Capacity | Max.400000 kcal/h(465 KW) |
| Solid Waste | Max.400 l/load |
| Combustion Chamber Temperature | Max.1200 |
| Surface Temperature | 15 above ambient temp. |
| Flue Gas Temperature | 350 |
| Flue Gas Back Pressure | Max.150mm W.C. |
| Combustion Chamber Negative Pressure | from 10 to 35 mm W.C. |
| Max.Rated EL.Power | approx.11 KW |
