Marine Solid Waste Management System >> Marine Incinerator >> Dual-Function Incinerator >> Sludge Oil and Solid Waste TypeMarine Incinerator
 |
 |
| Product Name | Marine Incinerator |
| Product No. | MEPE402-SS001 |
| Waste Type | Solid Waste & Sludge Oil |
| Mounting Type | Vertically |
| Power Supply | 440V/60HZ 380V/50HZ |
| Calorie Capacity | Max.180000 kcal/h(210 KW) |
| Corresponding To | Max.22 l/h sludge oil (IMO defined sludge) |
| Solid Waste | Max.200 l/load |
| Combustion Chamber Temperature | Max.1200C° |
| Surface Temperature | 15C° above ambient temp. |
| Flue Gas Temperature | 350C° |
| Flue Gas Back Pressure | Max.100mm W.C. |
| Combustion Chamber Negative Pressure | from 8 to 15 mm W.C. |
| Max.Rated EL.Power | approx.8 KW |
