Marine Solid Waste Management System >> Marine Incinerator >> Dual-Function Incinerator >> Sludge Oil and Solid Waste TypeMarine Incinerator
 |
 |
| Product Name | Marine Incinerator |
| Product No. | MEPE402-SS008 |
| Waste Type | Solid Waste & Sludge Oil |
| Mounting Type | Vertically |
| Power Supply | 440V/60HZ 380V/50HZ |
| Calorie Capacity | 1177300 kcal/h(1369 KW) |
| Corresponding To | 162 l/h sludge oil (IMO defined sludge) |
| Solid Waste | 600 l/load |
| Combustion Chamber Temperature | Max.1200C° |
| Surface Temperature | 15C°above ambient temp. |
| Flue Gas Temperature | 350C° |
| Flue Gas Back Pressure | Max.200mm W.C. |
| Combustion Chamber Negative Pressure | from 10 to 35 mm W.C. |
| Max.Rated EL.Power | approx.40 KW |
| Total Weight | approx.4400kg |
