Product Name | Sewage Treatment Plant | |||||||
Product No. | MEPE057-SE | |||||||
Treatment Process | MBR | |||||||
Model | MEPE057-SE1 | MEPE057-SE2 | MEPE057-SE3 | MEPE057-SE4 | MEPE057-SE5 | MEPE057-SE6 | MEPE057-SE7 | |
Application Number | 50 | 100 | 150 | 200 | 300 | 400 | 500 | |
Maximum Number Of Users | 55 | 110 | 165 | 220 | 330 | 440 | 550 | |
Hydraulic Load t/d | 3.5 | 7 | 10.5 | 14 | 21 | 28 | 35 | |
Organic Load kg/d | 1.8 | 3.5 | 3.9 | 7 | 10.5 | 14 | 17.5 | |
Dimensions mm | 1500×1200×1400 | 2000×1800×1500 | 2000×2000×1800 | 2500×2000×2000 | 3000×2200×2200 | 3500×2400×2300 | 4200×2400×2300 | |
Max.Dimensions mm | 1900×1500×1600 | 1800×2000×1800 | 2000×2200×2000 | 2200×2400×2200 | 2500×2500×2200 | 3500×2500×2200 | 4500×2700×2200 | |
Empty Weight(kg) | 1650 | 2500 | 2800 | 3200 | 3600 | 5300 | 6500 | |
Wet Weight(kg) | 5400 | 7700 | 10200 | 12500 | 15000 | 22000 | 28000 | |
Discharging Standard | Coliforms<100p/100ml;SS<35mg/l;BOD5<25 mg/l;COD<125 mg/l;PH=6~8.5 |
