Marine Sewage Treatment System >> Sewage Treatment Plant >> Sewage Treatment Plant
Product Name Sewage Treatment Plant
Product No. MEPE117-SE
Treatment Process Biofilm Process
Parameters Type MEPE117-SE1 MEPE117-SE2 MEPE117-SE3 MEPE117-SE4 MEPE117-SE5 MEPE117-SE6 MEPE117-SE7
Application Number 10-12 20-25 50-60 100-120 200-230 300-360 500-560
Average m3/d 0.77 1.45 3.98 7.65 14.5 22.5 40
Peak m3/h 0.1 0.32 0.48 0.92 1.74 2.81 4.82
Oranic Load kg BOD5/d 0.27 0.54 1.35 2.7 5.4 8.1 13.5
Airpump Type CYBW-10 CYBW-20 CYBW-40
Model Vane
Displacement m3/h 10 20240
Pressure kPa 60
Power kw 0.37 0.75 21.1
Smashpump Type 0.5CWF-10 1CWF-11 2CWF-11
Model Centrifugalknifetype
Displacement m3/h 5 10 20
PressureMPa 0.08 0.11 0.11
Powerkw 0.75 1.5 2.2
Dischargepump Type 25CGW-10-15 32CGW-15-20 40CGW-15-30
Displacement m3/h 10 15 15
Pressure Mpa 15 20 30
Power kw 1.1 1.5 2.2
Power Supply AC 380V/50Hz/3
Model Of Operation Automatic or Manual
