Centrifugal Oil Separator >> Single Separator >> Mitsubishi Type >> Marine Oil Separator
Product Name:Marine Oil Separator
Product NO.:MOHS201COS-101
Features:
Compact design realizes"Saving Energy&Space"
Higher rotating speed of bowl achieves higher separation performance.
Built-in Impeller pump
Purification up to density of 991kg/m3 at 15℃
Multi-monitor system integrated with detection and display functions
Highly reliable G-HIDENS system.
Technical Parameters
Model No. Actual Capacity Electric Motor (Kw) (G/GH)
Marine Dieseloil Heavy Fuel Oil
mm2/s/40℃ mm2/s/50℃
Viscosity 14 180 380 500 600 700
Separating Temp. 40℃ 98℃
SJ10G/GH 2900 1600 1150 890 790 720 3.7/5.5
2900 1650 1200 930 830 760
SJ20G/GH 4350 2450 1750 1400 1250 1150 5.5/7.5
4350 2600 1850 1450 1300 1200
SJ30G/GH 7800 4500 3200 2550 2250 2050 5.5/7.5
7800 4700 3350 2650 2350 2150
SJ50G/GH 11600 6900 4900 3900 3450 3150 7.5/11.0
11600 6950 4950 3950 3500 3200
SJ60G/GH 13300 8000 5700 4500 4000 3700 11.0/11.0
13300 8100 5750 4550 4050 3700
SJ70G/GH 15900 9800 6950 5500 4900 4500 11.0/11.0
15900 9750 6950 5500 4900 4500
SJ100G/GH 21800 14100 10000 7900 7050 6450 15.0/18.5
21800 14200 10100 8000 7100 6500
SJ120G/GH 24500 16300 11600 9200 8150 7450 15.0/18.5
24500 16500 11700 9250 8250 7550
SJ150G/GH 29200 20500 14600 11600 10300 9400 18.5/18.5
29200 20400 14500 11500 10200 9300
Note) Model G:Standard Model
Upper:60HZ
GH:HIDENS Model
Lower:50HZ
(Special model for partial discharge is option)
SUCTION PUMP CAPACITY TABLE(L/H)
Model NO. GP10G GP20G GP30G GP50G GP70G GP100G
60HZ 1300 2100 3600 5700 8200 11600
50HZ 1050 1750 3000 4750 6800 9650
