Hydrophore >> Sea Water Hydrophore >> Combination Sea Water Hydrophore
 |
 |
 |
|||
| Product Name | Combination hydrophore | ||||
| Technical Data | |||||
| Product No. | Capacity | Working pressure | Type of pump | Motor power | Remark |
| M³ | Mpa | KW | |||
| MFWS201-CH001 | 0.12 | 0.4 | 1WZ-0.9 | 1.5 | Horizontal water pump |
| MFWS201-CH002 | 0.2 | 1WZ-0.9 | 1.5 | ||
| MFWS201-CH003 | 0.3 | 1.5CWX-2 | 2.2 | Horizontal water pump | |
| 40CLH-2B | 3 | Vertical water pump | |||
| MFWS201-CH004 | 0.5 | 1.5CWX-2A | 2.2 | Horizontal water pump | |
| 40CLH-3B | 4 | Vertical water pump | |||
| MFWS201-CH005 | 1 | 1.5CWX-4A | 4 | Horizontal water pump | |
| 40CLH-3B | Vertical water pump | ||||
| MFWS201-CH006 | 1.5 | 1.5CWX-4A | 4 | Horizontal water pump | |
| 40CLH-3B | Vertical water pump | ||||
| MFWS201-CH007 | 2 | 1.5CWX-4A | 4 | Horizontal water pump | |
| 50CLH-4.5B | 5.5 | Vertical water pump | |||
| Main Features | It includes hydrophore, pumps, pressure switch and electric control box.Easy to install and maintain. | ||||
| Above techincal data are only for reference. We can redesign it according to your requests. For further details please contact us. | |||||
