Product Name	Marine Water Cooled Chiller
Product NO.	MACS030-CH
Specifications
Model Item			CH011	CH023	CH058	CH070	CH082	CH093	CH140	CH151	CH175	CH210	CH230	CH290	CH350	CH560	CH800	CH118

Cooling Capacity		kW	11.6	23	58	70	82	93	140	151	175	210	230	290	350	560	800	1180
Cooling Medium			R22(R134A,R404A,R407C)
Power Supply	Main Circuit		AC 380V 3P 50Hz/AC 440V 3P 60Hz
	Control Circuit		AC 220V 1P 50Hz/AC 220V 1P 60Hz
Protection Devices			Freon high pressure,freon low pressure,(oil pewssure),water stop,lack phase,overload and safty valves.
Compressor	Type		Hermetic or semi-hermetic compressor
	Energy Regulation	%	/		0,50,100 (or 0,66,100)				0,50,75,100 (or 0,50,66,100)
	Motor Power	kW	4.2	6.6	19	22	24	26	44	48	52	60	66	81	105	150	264	292
Condenser	Type		Horizontal Shell and Tube
	Water Inlet Temp	℃	≤32
	Water Flow	m3/h	3	7	17	20	23	26	40	42	50	60	65	80	100	150	220	310
	Water Pressure Lose	kPa	≤50		≤70			≤80
Drier Evaporator	Type		Hermetic or semi-hermetic compressor
	Water Inlet and Outlet Temp	℃	12/7

	Frozen Water Flow	m3/h	2	4	10	12	14	16	24	26	30	36	40	50	60	96	137.6	203
	Water Pressure Lose	kPa	≤60					≤100

Weight		kg	600	800	1350	1500	1600	1800	2400	2600	3000	3200	3000	3200	3500	4800	6000	9600
