Product Name:Marine Oil Separator |
||||||||
Product NO.:MOHS201COS-404 |
||||||||
Product Feature: |
||||||||
Automatic control such as water control,pneumatic control,temperature control,buzzer control ,discharge automatically |
||||||||
High efficiency |
||||||||
Low oil consumption |
||||||||
Convenient operation and economic maintenance cost |
||||||||
Application: |
||||||||
The product is mainly used in cleaning away,content and impurities in fuel and lubricating oil of ship diesel engine,it can also used for purification and clarificaion of other mineral oil as well as similar products in the fields such as chemicals,food,pharmaceutical,ect. |
||||||||
Technical Parameters |
||||||||
| Type | Rated Capacity | Discharge Type | Outlet Pressure | Motor Power | Weight | Demension | ||
| L/h | Mpa | kw | kg | L×B×H(mm) | ||||
| KYDH206 SD-23 | 2000 | Automatic | ≥0.2 | 5.5 | 713 | 1095×792×1247 | ||
Condition For Mineral Oil Separation And Actual Capacity |
||||||||
| Oil Type | Fuel Oil | Lubrication Oil | ||||||
| Fuel Oil | Heavy Fuel Oil | SAE30,40 | Detergency Oil | Steam Turbine Oil | ||||
| Kinematical Viscosity | 1.9-5.5 | 5.5-24 | 120 | 180 | 380 | 100-120 | 61.2-74.8 | |
| 40℃ | 50℃ | 40℃ | 40℃ | |||||
| mm2/s | ||||||||
| Density | <900 | 900-991 | 880-900 | <900 | ||||
| Kg/m3 20℃ | ||||||||
| Separating Temperature | 40-60 | 90-98 | 80-95 | |||||
| ℃ | ||||||||
| Recommended Capcity | 4500 | 4000 | 2200-2400 | 1800-2000 | 1400-1600 | 2000-2400 | 1000-1200 | 3200-3400 |
| L/h | ||||||||
