Product Name:Oil Filter |
|||||
Product NO.:MOHS402OF-206 |
|||||
Product Description: |
|||||
The products are usually used for diesel engine,broadly used fuel oil&lubricating oil line's filter and large filter's surface,few pressure difference,long periods. |
|||||
Technical Parameters |
|||||
| Type | Caliber DN | Flow Rate | Working Press. | Working Tem. | Clean Press. Drop |
| mm | m3/h | Mpa | ℃ | Mpa | |
| SPL | 15 | 2 | ≤0.8 | ≤95 | ≤0.15 |
| 25 | 5 | ||||
| 32 | 8 | ||||
| 40 | 12 | ||||
| 50 | 20 | ||||
| 65 | 30 | ||||
| 80 | 50 | ||||
| 100 | 80 | ||||
| 125 | 120 | ||||
| 150 | 180 | ||||
| 200 | 320 | ||||
