| Free Fall Life Boat Launching Appliance | |||||||
| Product No. | L×H×B (m) | Max.Working Load (Kn) | Max Hoisting Load (Kn) | Winch Drum Capacity (m) | Hoisting Speed (m/min) | Design Condition | Chute Angle |
| MLSE701-LG55 | 55 | 42 | 45 | ≥3.0 | 20°List10°trim | 35° | |
| MLSE701-LG65 | 7400×6430×3270 | 65 | 42 | 50 | ≥3.0 | 20°List10°trim | 35° |
| MLSE701-LG65-B | 7400×6430×3270 | 65 | 42 | 50 | ≥3.0 | 20°List10°trim | 35° |
| MLSE701-LG70 | 70 | 45 | 50 | ≥3.0 | 20°List10°trim | 35° | |
| MLSE701-LG75 | 75 | 50 | 75 | ≥3.0 | 20°List10°trim | 35° | |
| MLSE701-LG90 | 90 | 70 | 90 | ≥3.0 | 20°List10°trim | 35° | |
| MLSE701-LG145 | 145 | 120 | 145 | ≥3.0 | 20°List10°trim | 35° | |
