 Marine Communication System >> Internal Communication System >> Public Address >> HKD Public Address/Talk Back
HKD Public Address/Talk back
Product No: MEIC205
HKD PA system is used for commanding,communication,talk-back,G/A,and paging
for various vessels.It's also appliCable to ports,platforms and other projects.
The system is available in different versions.
Model and Features:
FEATURES/MODEL HKD-□C HKD-□D HKD-□E HKD-□F
1)Use MIC to paging,and output through single or several way of speakers √ √ √ √
2)The main unit is equipped with monitor speaker and volume knob √ √ √ √
3)4 outputs: loud-hailing,machine area,indoor,outdoor several models with 7 outputs:dual machine area,indoor,outdoor 4 4 7 7
4)Interface to automatic telephone exchange for paging ＼ √ √ √
5)Remote Control of outputs through single way or several ways of speakers ＼ 2 remtote stations 6 remote stations 6 remote stations
6)Talk back among PA main unit,remote station and talk-back station ＼ √ √ √
7)When the loud hailing speaker works,other speakers will shut up automatically speakers for machine area and indoor have volume override function √ √ √ √
8)With features of general emergency alarm and fire alarm.The alarm will be output through speakers when alarming. ＼ √ √ √
9)FM/AM/MP3 player FM/PM3 FM/PM3 √ √
10)Power supply: 220VAC,24VDC,change-over automatically.110VAC is optional √ √ √ √
11)Fire remote station used for passenger ship ＼ ＼ ＼ √
12)Use VHF Wireless talk-back station to Control the PA to output through one or several ways of speakers ＼ Customized Customized Customized
PRODUCT LIST:
Number Model Description Weight IP Class Color
Type D.E Public Address System
1 HKD-2X□E Public Address Main Unit(50-400) 14-40kg IP20 Off-White
2 HKD-□D Public Address Main Unit(50-200) 8kg IP20 Dull Black
3 RM-1Q Main Remote Control Station 1.8kg IP20 Dull Black
4 RM-1K Flush Type Remote Control Station 0.9kg IP20 Dull Black
5 RM-1G Weatherproof Remote Control Station 2kg IP44 Grey
6 RM-1F Wall Type Remote Control Station 6.4kg IP56 Off-White
Type F Public Address System
7 HKD-2X□F Public Address Main Unit(50-400W) 14-40kg IP20 Off-White
8 RM-1QF Main Remote Control Station 1.8kg IP20 Dull Black
9 RM-1M Wall Type Remote Control Station 2kg IP44 Grey
10 RM-1GF Wall Type Remote Control Station 2kg IP44 Grey
11 RM-1FF Weatherproof Remote Control Station 6.4kg IP56 Off-White
Standard
12 DP700 Explosion-Proof Remote Control Station 2.5kg IP44 Blue
13 YDC-□Q Flush Type Speaker(0.5-5W) 1.2kg IP20 Milk White
14 YDC-□G Wall Type Speaker(0.5-5W) 1.2kg IP22 Grey
15 YDC-□P Wall Type Speaker(0.5-5W) 1.2kg IP44 Grey
16 YDC-□T Toilet Speaker(0.5-1W) 0.5kg IP56 Milk White
17 YDC-□1 Double Face Speaker(3-5W) 2.2kg IP22 Off-White
18 YDC□-1 Horn Speaker(5-100W) 3.1-12kg IP56 Grey
19 YDC□-EX Explosion-Proof Speaker(5-25W) 5kg IP56 Lake Green
20 CZB-1 Port & Starboard MIC Box 0.5kg IP44 Grey
21 ZT-1 Speaker Rotating Unit 16kg IP56 Off-White
22 RM-1B General Emergency Alarm Controller 1kg IP20 Dull Black
23 SC-A Talk-Back Station 1kg IP20 Dull Black
