Marine Fire Suppression System >> Parts >> Fire Pumps >> External Fire PumpsHorizontal Single Stage Double Suction Bottom Suction Top Discharge Centrifugal Pump
 |
 |
||
| Product name: | Horizontal Single Stage Double Suction Bottom Suction Top Discharge Centrifugal Pump | ||
| Product No. | MFFE006-CXB1 | ||
| Speed | 2960rpm | ||
| Capacity: | 300m3/h | ||
| Total head | 145m | ||
| Power absorbed | 145kw | ||
| efficiency | 83% | ||
| NPSHr | 5.8m | ||
| Inlet | DN200 | ||
| Outlet | DN150 | ||
| Materials: | |||
| Pump shell | Ni-Al-bronze/ Nod.CI GGG50 | ||
| Impeller | Ni-Al-bronze | ||
| Shaft | Stainless steel | ||
| Bear | SKF | ||
| Sealing | Soft sealing | ||
