Marine Fire Suppression System >> Parts >> Foam Equipments >> Fixed Foam EquipmentsFixed Fire Monitor
 |
 |
||
| Product name: | Fixed Fire Monitor | ||
| Product No. | MFFE005-FM007 | ||
| Descriptions: | Produced on requirement | ||
| Effective capacity: | 18000L/min | ||
| The max pressure: | 16bar | ||
| Inlet | Flange DN150 PN16 | ||
| Outlet | Flange connection | ||
| optional inlet flange: | DN200/ ANSI6" | ||
| rotation range | |||
| Horizontal: | 360℃ infinite | ||
| Vertical: | +75℃~ -45℃ | ||
| Weight: | ~165Kg | ||
| Materials: | |||
| Nody: | Stainless steel/Anti-corrosion aluminum alloy/Copper alloy | ||
| Sealing: | NBR | ||
| Pipe: | Hard aluminum alloy | ||
| Flange: | Stainless steel/Anti-corrosion aluminum alloy/Copper alloy | ||
| Painting: | Red RAL3000 | ||
| The manitor can be arrested in any horizontal or vertical position. | |||
